Supply and Delivery of Medium Voltage Switch Gears, Automatic Transfer Switch , Low Voltage Boards and a Step-Up Transformer to the United Nations Entebbe Support Base, Uganda.

Item Description:

United Nations Procurement Division/Regional Procurement Office (UNPD/RPO), hereby invites qualified and Competent Companies to submit their expressions of interests to establish a One- off Supply and Delivery of Medium Voltage Switch Gears, Automatic Transfer Switch , Low Voltage Boards and a Step-Up Transformer as listed below, delivered on DAP United Nations Entebbe Support Base, Uganda (Incoterms 2010). 1.Medium Voltage Switch Gears. Supply and deliver MV switch gear 11KV,630A, 12.5KA/1s, 1 incomer 1 outgoing,12KV surge arrestors with VCB/SF6 circuit breakers 630A, line earth switch, protection relays with IEC61850 communication, digital multimeters and all accessories. 2.Auto Transfer Switch. Supply and deliver Auto transfer switch (MV ATS) 630A, 12.5KA/1s, 2 incomer 1 outgoing, complete with Automatic transfer unit with IEC61850 protocol, VCB/SF6 circuit breaker with all accessories. 3. Low Voltage Boards. Supply and deliver 11-way monobloc LV panel board with copper Bus-bars 1000A rated, network analyzer and measuring instruments, phase monitor relay, type 2 surge arrestors complete with all accessories. 4.Step-Up Transformer. Supply and deliver 2500KVA step-up transformer 415V/11000V step-up transformer with vector group YNd11 cooling ONAN, copper wound conductor, buchholz relay and conservator tank, with marshalling box and protection relay as IEC61850, complete with all accessories.

Click here to open EOI document
