Supply and Delivery of PDA Bar Code Readers

SPECIFIC REQUIREMENTS / INFORMATION (IF ANY)

ONPASS MACHINES

1/ PHYSICAL CHARACTERISTICS:

Iltrimate in Ultra-rugged Enterprise-Class all Touch Computing

• Dimension: 6.3 in. L x 3.3 in. W x 1.1 in.D
• Weight 13.3 oz / 376g
• Display: 4.7 in. High Definition (1280 x 720) exceptionally bright, outdoor viewable; optically bonded to touch panel
• Imager Window: Corning Gorilla Glass
• Touchpanel: Dual model capacitive touch stylus, finger or gloved fingertip input (conductive stylus sold separately); Screen Protector and Rain modes; Corning Gorilla Glass
• Backlight: LED backlight
• Power: Li-Ion 3.7V, 4620 mAh. PowerPrecision / PowerPrecision +: Improved battery technology for longer cycle time and read-time visibility into battery metrics for better battery management
• Expansion Slot: User accessible MicroSD with 32 GB and up to 256 GB SDXC
• SIM: only 2 Nano SIM slots (Dual SIM, Dual Stand-by – EU only)
• Network: WWAN (cellular, WLAN (WiFi), WPAN (Bluetooth); USB 2.0 High Speed (host and client)
• Notification: Audible tone; multi-color LEDs; vibration
• Key[ad: On-screen tone keypad and Enterprise Keyboard
• Voltage and Audio: Three micro support with noise cancellation; vibrate alert; speaker; Bluetooth wireless headset support, high quality speaker phone; PTT headset support; cellular circuit switch voice; HD Voice

2/ PERFORMANCE CHARACTERISTICS:

• CPU: Qualcomm Snapdragon TM 660 octa-core,2.2 GHz
• Operating System: android 11; upgradeable to Android 14
• Memory: 4 GB RAM/32 GB Flash pSLC
• Internet Protocal: IPv4 and IPv6 –

3/ USER ENVIRONMENT:

• OPerating Temp: -4o F to 122o F/-20o to 50o C
• Storage Temp: -40oF to 158oF/-40o to 70oC
• Humidity: 50% to 90% non-condensing
• Drop Specifications: Multiple 6ft/1.8 m drop to concrete across full operating temperature range, multiple 8ft /2.4 m drop to concrete at room temperature per MIL-STD 810G
• Tumble specifications: 2,000 3.3 ft/1.0 m tumble; meets and exceeds IEC tumble specifications
• Scaling: IP65 and IP68 per applicable IEC sealing specifications
• Vibration: 4g’ s PK Sine (5 Hz to 2 kHz); 0.04 g 2/Hz Random (20 Hz to 2 kHz); 60 minute duration per axis, 3 axis
• Thermal Shock: -40o F to 158o F/ -40o C to 70o C to rapid transaction
• Electrostatic Discharge (ESD): +/-15kVdc air discharge; +/-8kVdc indirect discharge

4/ INTRACTIVE SENSOR TECHNOLOGY (IST):

• Light Sensor: Automatically adjusts display backlight brightness
• Motion Sensor: eCompass, 3-axis Gyro, 3-axis accelerometer
• atmospheric Pressure sensor

5/ DATA CATURE:

• Scanning: SE4770: 1D/2D omnidirectional image
• SE4750: 1D/2D omnidirectional image
• Digimarc Symbology support
• Camera: Front – 5MP fixed focus
• Rear – 13MP autofocus; f2.4 aperture; flash LED generates balanced white light; supports Torch mode; 4K video with image stabilization Camera supports barcode scanning
• NFC: ISO 1443 Type A and B; F; FeliCa and ISO 15693 cards; P2P mode and Card Emulation via Host
• SAM support for Calypso, Felicia and Mifare technology: Dual SAM support on TC77 SAM SKU
